5M Geodesic Dome Tent - 16.4 ft
Brand: Sheltent
Material: Double Coated Polyester PVC, Q235 Steel
Cover Transparency: 30% Transparent and 70% Opaque
Product Dimensions: 16.4 ft (5 m)
Center Height: 9.5 ft (2.9 m)
Floor Space: 211.0 ft² (19.6 m²)
Special Feature: Flame retardant, Corrosion resistant, UV protection, 100% Waterproof
Regular price
$3,199.99
Regular price
$3,199.99
Sale price
$4,000.00
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
Customer Winning Service Experience
Customer Winning Service Experience
White glove service relationship, we're your partner for the long term.
High Quality, Reliably Crafted Materials
High Quality, Reliably Crafted Materials
UV-protected materials and stitching.Anodized aluminum frames/poles that won't fray, chip, or rust.
30 Days Money-Back Guarantee
30 Days Money-Back Guarantee
Return your undamaged Sheltent products for ANY reason, within 30 days, and you'll receive a full refund.
Welcome to the future of outdoor living! Our 5m (16.4 ft) Geodesic Dome Tent not only has a unique design but also has excellent stability and durability. Whether it is family camping, outdoor activities, or private parties, this tent can provide you with spacious space and a comfortable environment.
Strong and Corrosion-resistant Frame
The main structure of the 5m geodesic dome tent is made up of Q235 steel and its surface can be white-coated, black-coated, or galvanized to enhance corrosion resistance. This is especially important for outdoor dome tents, as the stability and strength of the tent frame should be guaranteed to protect you from the elements.
Since surface-treated steel frames don't rust easily, they also help you reduce the frequency and cost of routine tent maintenance.
Robust Wind and Snow Resistance
At Sheltent, a geodesic dome tent with a 25*1.5 mm rough frame can withstand wind speeds of up to 120 km/h (74.5 mph) and has a snow load of 51 kg/m² to cope with heavy snow cover. Whether it's a storm or heavy snow, this tent offers reliable protection and security.
High-Quality PVC Cover
We use 850 g/m² (25 oz /yd²) double-coated opaque PVC and find that compared to another cover on the market, the weight and density are higher and therefore have a stronger fiber structure. Not only does it have better abrasion resistance, it is also generally more waterproof.
Our geodesic dome tent cover also features an IV-rated UV coating. It’s the first line of defense against UV damage from sun exposure, giving you a shady and comfortable experience. Besides, PVC meets the class B1 building materials requirements of DIN 4102-1, which can ensure the safety of you and your guests in time.
Spacious Space and Wide Range of Applications
The 16.4 ft (5 m) geodesic dome tent has 211 square feet (19.6 m²) of interior space. This spacious space is suitable for people who love outdoor camping, short-term stays, birthday party celebrations, and family get-togethers.
The 9.5 ft (2.9 m) center height provides enough space on top and good ventilation, ensuring airy and comfortable accommodation for up to 3 people.
Geodesic Structure for Appealing Aesthetics
Spherical structures typically fall into two categories: geodesic and lamella structures. Geodesic structures are crafted from many short, straight segments that form a geometrically shaped sphere. They're great at distributing stress evenly, which makes them super robust yet lightweight.
On the other hand, lamella structures consist of square or rectangular units arranged in a grid pattern. While they offer stability, they often lack uniform stress distribution and the aesthetic appeal of geodesic designs.
For our 5m dome tent, we recommend the geodesic structure. This design is visually closer to a perfect sphere enhancing the tent's aesthetics. The uniform force distribution effectively improves stability and wind resistance. As a value for money and cost-effective choice, geodesic structure maximizes material efficiency and reduces waste for excess costs.
All Season with Insulation Layer
Our geodesic dome tent is equipped with an innovative insulation layer not found in other competitors, from the design point of view to the choice of materials. The insulation layer consists of a 16-ounce canvas and an aluminum foil bubble, which is not only waterproof and mildew-resistant but also has a warm lining that creates a soft and cozy living environment.
For spring and summer in most areas, you can enjoy the coolness by just installing air conditioning in the dome tent. However, in the cold winter, the aluminum foil bubble sheet can ensure a warm environment by significant thermal insulation up to 15 degrees.
For example, if the temperature outside is as low as -5 degrees Celsius, the tent can maintain warmth up to 10 degrees Celsius, keeping you comfortable in cold conditions. Additionally, this design saves up to 70% on energy costs and is therefore environmentally friendly.
Precision Manufacturing
Traditionally, fragmented fabrics are spliced together using velcro and tie rope, causing the fabric to wobble in the wind and allowing rainwater to seep in easily. In contrast, we use a hot pressing machine to splice the fabrics to create a smooth tent appearance. This method significantly improves the tent's performance in drainage and wind resistance.
The assembly of the frame also tests the craftsmanship of the manufacturers. We use advanced CNC technology to ensure the precision of each steel tube length and screw hole so that we can ensure each component fits together perfectly.
Additionally, Sheltent's strict inspection system checks the thickness and hardness of each steel tube to ensure you feel free of security when using the 5m geodesic dome tent.
Modular Design for Easy Installation
We know that people who choose a 5m geodesic dome tent focus on ease of assembly and portability. Therefore, we prefabricate the Q235 steel frame at the factory. After delivery to the site, 3-5 skilled adults can assemble the tent in 6-8 hours.
A geodesic dome tent cannot be built on uneven or soft ground; the floor must be solid and robust. We have considered this and now offer modularized deck structures composed of high-quality Q235 steel with prefabricated bases.
You can easily assemble the dome platform and tent’s legs to lift the overall structure by 0.5m. This elevation protects the tent from moisture and mosquitoes. With the modular dome platform, you don't need solid ground to set up the tent. It ensures stability even in challenging terrains such as grasslands and deserts.
Fully Equipped
In addition to the basic steel frame and PVC cover, Sheltent's 5m geodesic dome tent comes with a comprehensive range of accessories, helping you quickly achieve installation without additional purchase!
- Insulation: aluminum foil bubble insulation + canvas fabric (beige/grey), waterproof, mold resistant and fire retardant
- Curtain: curtain fabric with optional textures and colors
- Solar Extractor Fan: 35W high efficiency, remote control with dual mode (strong mode & silent mode)
- Glass Window: φ500mm lockable porthole round glass window with aluminum alloy frame
- Triangle Window: triangle PVC fabric window, rolling with buckle fastener
- WPC Door: black coated aluminum frame with 3 color options (grey, brown, dark brown)
- Structural Report with calculated wind and snow loads
Easy to Setup
5M Geodesic Dome Tent Specifications
| Diameter | 5m (16.4 ft) | V Frequency | 3V |
|---|---|---|---|
| Tent Style | Glamping Dome | Commercial Grade? | Yes |
| Center Height | 9.5 ft (2.9 m) | Water Resistant | Yes（40kpa waterproof） |
| Total Square Feet | 211.0 ft² | UV Coated | Yes（IV） |
| Dome Weight | 400kg | Flame Resistant | Yes（B1） |
| Cover Color | White/Dark Green/Beige | Custom Logo Printing | Yes |
| Fabric Translucency | Blockout | Wind Resistance | 120 km/h (74.5 mph) |
| Tent Top Material | 850 g/m² double coated opaque PVC | Snow Load | 51 kg/m² |
| Structure Frame | Q235 Steel |
About Packaging
Get a 5M (16.4 ft) Geodesic Dome Tent Now from Sheltent!
Sheltent is delighted to serve you a 16.4 ft geodesic dome tent to make your event distinctive and memorable. We are always striving to supply the greatest rates possible while also ensuring your total satisfaction. With our state-of-the-art processing centers, we cut out middlemen to bring you lower prices
As a tent manufacturer specializing in factory direct sales, we take pleasure in our ability to provide inexpensive prices. Whether you're organizing a wedding, a corporate exhibit, or another event, we can offer you the most cost-effective option. Please feel free to contact our customer service team, who are always glad to assist and answer any queries you may have concerning timeliness or modification.
Features of 5M Geodesic Dome Tent - 16.4 ft
